| MACHINE MODEL | FD1912S |
| PRINTHEAD | EPSON S 3200,THE NUMBER OF PRINTHEADS: 12 |
| Print Width | FEED WIDTH S1950MM, EFFECTIVE SCREEN WIDTH ≤1900MM |
| PRINT MEDIUM | THERMAL TRANSFER PAPER |
| PRINTING SPEED | 1PASS:1100㎡/H，2PASS:620㎡/H，3PASS:410㎡/H，4PASS:310㎡/H |
| MEDIUM TRANSFER | RUBBER ROLLER MODE |
| DRYING METHOD | EXTERNAL INTELLIGENT AIR-HEAT INTEGRATED DRYER |
| MOISTURIZING MODE | FULLY SEALED FOR AUTOMATIC MOISTURIZING AND CLEANING |
| RIP SOFTWARE | SUPPORT MAINTOP6.1, PHOTOPRINT, ONYX, NEOSTAMPA AND OTHER SOFTWARE STANDARD WITH FEIDI DEEP CUSTOMIZATION VERSION OF RIP |
| PRINTING MODE | INKJET PRINTING |
| PICTURE FORMAT | JPG, TIF, PDF, ETC. |
| SYSTEM CONFIGURATION | WIN7 64-BIT/WIN10 64-BIT, HARD DISK: 500G OR ABOVE (SSD IS RECOMMENDED), MEMORY: 16G OF OPERATING MEMORY, GRAPHICS CARD: AT DISCRETE 4G OF MEMORY. CPU:I7 PROCESSOR,TRANSFER INTERFACE: USB 3.0 |
| STANDARD CONFIGURATION | INTELLIGENT DRYING SYSTEM, INTEGRATED THREE-COLOR LIGHT ALARM SYSTEM CONTINUOUS INK SUPPLY SYSTEM, 10.000-METER UNWIND. NEGATIVE PRESSURE CIRCULATION DEVICE, MAGNETIC LEVITATION MOTOR MODULE |
| WORKING ENVIRONMENT | TEMPERATURE: 18°C-30°C,HUMIDITY: 35%-65% |
| POWER REQUIREMENTS | INPUT VOLTAGE: 220V AC 73A PRINTING SYSTEM: 7KW DRYING SYSTEM: 18KW |
| MACHINE SIZE | APPEARANCE SIZE: 4000*1000*1870 MILLION METERS PUT AWAY BASE: 2575*1061*1115 PACKING SIZE: PRINTING UNIT:4150*1370*2140MM, BASE UNIT: 2700*1100*1365MM |
